4th Axis Drive & Wiring
24 Station Side Mounted Tool Changer
Haas Renishaw Wireless Intuitive Probing Package with Spindle Probe
10,000 RPM Spindle
Auger Style Chip Conveyor
Remote Jog Handle
Programmable Coolant Nozzle
Rigid Tapping
Coordinate Rotation & Scaling
Spindle Orientation
User Definable Macros
Visual Quick Code Programming
1 MB Programming Memory
2 Speed Gearbox
Coolant System with Tank & Pump
USB Port Interface
RS 232 Port Interface
A Few Miscellaneous Tool Holders
**Workholding Vises Seen In Photos Are Not Included With Machine**
**7,474 Cycle Start Hours**
**6,215 Feed Cutting Hours**
Table size: 52" x 23"
Table load capacity: 4,000 lbs.
X-axis travel: 50"
Y-axis travel: 26"
Z-axis travel: 25"
Spindle nose to table: 4.2" - 29.2"
Spindle motor: 20 HP - 2 Speed Geared
Spindle taper: CAT 40
Spindle speeds: 0 - 10,000 RPM
Tool magazine capacity: 24 Position ATC Side Mount
Cutting feedrates: 500 IPM
Rapid traverse rates: 710 IPM
Machine dimensions lxwxh: 148"x102"x118"
Machine weight: 14,600 lbs.
