All Terrain Scissor Lift | Work Height: 47 ft
Platform Height (Raised): 41 ft
Platform Interior Dimensions: 11’2″ × 5’7″
Extension Deck: 4 ft roll-out
Overall Length: 139 in
Overall Width: 87 in
Stowed Height (Rails Up): 114 in
Stowed Height (Rails Down): 87.5 in
Ground Clearance: 8 in
Operating Weight: ~10,840 lb
Gradeability: 30%
Drive Speed (Stowed): 3.5 mph
Drive Speed (Raised): 0.6 mph
Turning Radius (Inside/Outside): 13.2 ft / 20.7 ft
Lift Time (Loaded): ~56 seconds
Lower Time (Loaded): ~53 seconds
Total Capacity: 1,500 lb
Capacity with Dual Extensions: 1,000 lb
Max Occupants: 5
Standard Engine: GM 1.6L Vortec (dual-fuel, 65 hp)
Optional Engine: Kubota 3-cylinder diesel
Drivetrain: 4×4 with limited-slip differential
Tires: 10×16.5 grip-lug (air-filled, foam-filled optional)
Drive at full height
Tilt alarm with automatic function cut-out
Fold-down rails
Spring-loaded entry gate
Rear disc brakes
110V GFI outlet on platform
Motion alarm and flashing light
Optional: diesel scrubber, outriggers, cold weather package, hydraulic generator, tool tray, telematics
| Weight | 10840.0 | 10840.0 |
Status: Available
Hours: 2916
Weight: 10840.0
Rental Rate: $2200
Rate Schedule: DAY: $330
Rate Schedule: WEEK: $733
Rate Schedule: 3 MOS: $6600
Rate Schedule: 6 MOS: $13200
