EROPS (Cab) A/C, Heat, Wide Tracks, PAT-Blade, w/Leica GPS Technology ||| Engine: FPT F4HFE613F A002, Tier 4 Final certified
Gross Power: 138 hp
Net Power: 127 hp @ 2000 rpm
Displacement: 6.7 L (409 in³), 6-cylinder, direct injection
Transmission & Drive
Transmission: Dual-path hydrostatic
Control: Single-lever with electronic straight tracking
Max Travel Speed: 5.8 mph forward/reverse
Performance
Maximum Drawbar Pull: 48,000 lb
Hydraulic Flow: 34.9 gpm
Hydraulic Pressure: 2,830 psi
Dimensions & Weight
Operating Weight:
Long Track: 31,134 lb
Wide Track: 32,174 lb
LGP: 32,637 lb
Blade Width: 120–132 in
Blade Capacity: 3.8–4.2 cu yd
Height (to cab): 116 in
Track Width (over tracks): Approx. 8 ft
Shoe Width: 30 in
Ground Pressure
Approx. 5.3 psi
Operator Station
Cab: ROPS, climate controlled
Seat: Cloth, air suspension
Features: 12V outlet, dome light, dual wipers, optional radio
Blade Guidance: Compatible with Trimble, Leica, Topcon
Telematics: SiteWatch capable
Electrical
System Voltage: 24V
Batteries: Dual 12V, 925 CCA
Alternator: 120 A
| Weight | 32174.0 | 32174.0 |
Status: Available
Hours: 800
Weight: 32174.0
Rental Rate: $12000
Rate Schedule: DAY: $1800
Rate Schedule: WEEK: $4000
Rate Schedule: 3 MOS: $36000
Rate Schedule: 6 MOS: $72000
