Length To Fork Face: 221 In Width Over Tires: 98 In Height Overall: 99 In Wheelbase: 119.5 In Ground Clearance: 18 In Turning Radius Outside Tires: 160 In Rated Capacity: 8,000 Lb Maximum Lift Height: 42 Ft Maximum Forward Reach: 29 Ft Max Load At Max Reach: 1,600–1,800 Lb Max Load At Max Height: 6,000 Lb Operating Weight: 25,366 Lb Curb Weight: 23,840 Lb Fuel Capacity: 35 Gal Hydraulic Fluid Capacity: 53–60 Gal Engine: Cummins QSB4.5T Turbo Diesel, 4-Cylinder, 110 Hp Max Torque: 305 Lb-Ft At 1,500 Rpm Transmission: 4-Speed Forward, 3-Speed Reverse Powershift Travel Speed: 20 Mph Drawbar Pull: 24,000–25,000 Lb Boom Speed (Retracted): Up 15 S, Down 12.5 S Boom Extend/Retract: Extend 14.5 S, Retract 14 S Hydraulic Pump: Variable-Flow Piston Pump Steering: 2-Wheel Front, 4-Wheel Circle, Crab Steering (Power-Assist) Brakes: Inboard Wet Disc With Emergency Declutch Frame Leveling: ±10° Tires: 13.00×24 12-Ply (Foam-Filled Optional)
| Weight | 25365.0 | 25365.0 |
Status: Available
Weight: 25365.0
Rental Rate: $3990
Rate Schedule: DAY: $598
Rate Schedule: WEEK: $1330
Rate Schedule: 3 MOS: $11970
Rate Schedule: 6 MOS: $23940
