EROPS (Cab), A/C, Heat, Blade, 48" Bucket w/Teeth, 18" Trenching Bucket----Engine
Model: Yanmar 4TNV98CT-WBV
Type: Water-cooled, 4-cylinder diesel
Gross Power: 56.9 HP (42.4 kW) at 2,400 rpm
Emissions: Tier 4 Final compliant
Operating Weight
With Rubber Tracks: 18,136 lbs
With Steel Tracks: 18,268 lbs
Performance
Maximum Digging Depth: 15 ft 4 in
Bucket Digging Force: 11,332 lbs
Arm Digging Force: 8,356 lbs
Swing Speed: 9 rpm
Travel Speed: High – 2.8 mph, Low – 1.6 mph
Hydraulics
Hydraulic System: ViPPS (ViO Progressive 3-Pump System)
Pump Flow Capacity: 56.3 gal/min
System Relief Valve Pressure: 11,298 psi
Dimensions
Overall Length: 21 ft 2 in
Overall Width: 7 ft 5 in
Overall Height: 8 ft 8 in
Ground Clearance: 1.28 ft
Tail Swing Radius: 3 ft 9 in
Blade
Width: 7 ft 5 in
Height: 1 ft 6 in
Lift Above Ground: 1 ft 6 in
Dig Below Ground: 1 ft 7 in
Additional Features
True zero tail swing for tight-space maneuvering
Auto-shifting two-speed travel
Eco Mode and auto-deceleration for fuel efficiency
SmartAssist Remote for remote diagnostics
Comfortable cab with heat and A/C
| Weight | 0.0 | 0.0 |
Status: Available
Hours: 1660
Weight: 0.0
Rental Rate: $3000
Rate Schedule: DAY: $450
Rate Schedule: WEEK: $1000
Rate Schedule: 3 MOS: $9000
Rate Schedule: 6 MOS: $18000
Attachment: Severe Duty Bucket - Excavator 48in
Attachment: Trenching Bucket
