Skid Mounted Generator 120V/208V, Military Design, John Deere Engine |50 AMP Power Cord ($100|Month|$55 Week|$25 Day)|20 AMP Power Cord ($25|Month|$12.50 Week|$5 Day)|X-treme Power Distribution Box - Temporary Power Box, 50-Amp, 125/250V, GFCI ($175|Month|$80 Week|$25 Day)|200 Amp Magnum Distribtion Box w/Camlocks, 50 amp Twistlock Outputs Needed for MEP Generators If They Are Not Hard Wired ($400|Month|$200 Week|$50 Day) MEP-806B, NSN: 6115-01-462-0291, Engine: John Deere 6068TF151 Turbocharged Diesel 6-Cylinder 4-Cycle Liquid-Cooled, Displacement: 414 In³ (6.8 L), Rated Speed: 1,800 Rpm, Electrical Output: 60 Kw At 60 Hz (50 Kw At 50 Hz) Power Factor 0.8, Phase And Wiring: 3-Phase 5-Wire, Voltage Sets: 120/208 V Or 240/416 V Selectable With 50/60 Hz Capability, Adjustment Ranges: 60 Hz 197-240 V Or 395-480 V And 50 Hz 190-213 V Or 380-426 V, Parallel Operation: Yes With Same Class Units, Fuel Types: DF-1 DF-2 JP-8/F-24, Tank Capacity: 43 Gal, Fuel Consumption: 5.1 Gph Average And 4.7-4.9 Gph At Rated Load, Weights: 3,556 Lb Dry And 3,992 Lb Wet, Estimated Operating Weight With Full Fuel: 4,300 Lb, Dimensions (L × W × H): 87 In × 35.7 In × 59 In, Cube: 106 Ft³, Operating Temperature: -25 °F To +120 °F (To -50 °F With Winterization Kit), Noise: 70 Dba At 7 M (23 Ft), Overload Capability: 110% Short-Term, Altitude And Heat Derate: Rated At 4,000 Ft And 120 °F With Typical Derate 3.5% Per 1,000 Ft From 4,000-8,000 Ft, Construction: Fully Enclosed Skid-Mounted Brushless Alternator Digital Controls And Protective Fault System, Handling: Forklift Pockets And Trailer Mountable (E.G., MK353), Protective Shutdowns: Low Oil Pressure High Coolant Temperature Low Fuel Overspeed And Over-Voltage, Runtime Note: Approximately 8.4 Hours Per Tank At 5.1 Gph Average Load.
| Weight | 3992.0 | 3992.0 |
Status: Available
Weight: 3992.0
Rental Rate: $1755
Rate Schedule: DAY: $195
Rate Schedule: WEEK: $780
Rate Schedule: 3 MOS: $5265
Rate Schedule: 6 MOS: $10530
