Maximum working height: 46 ft Maximum platform height: 40 ft Maximum horizontal reach: 31 ft 8 in Below-ground reach: 1 ft Platform dimensions: 8 ft × 3 ft or 6 ft × 2 ft 6 in Overall width: 7 ft 6 in Overall height (stowed): 8 ft 2 in Overall length: 24 ft 3 in Wheelbase: 7 ft 3 in Ground clearance: 12.5 in Lift capacity (unrestricted): 500 lb Platform rotation: 160° hydraulic Turntable rotation: 360° continuous with approximately 2 ft 10 in tail swing Drive speed (stowed): 4.8 mph Drive speed (raised): 0.68 mph Gradeability: 30% (2WD) / 40% (4WD) Engine: Deutz diesel, 3-cylinder, approximately 49 hp Fuel tank capacity: 35 gal Hydraulic tank capacity: 38 gal
| Weight | 22429.0 | 22429.0 |
Status: Available
Weight: 22429.0
Rental Rate: $4240
Rate Schedule: DAY: $636
Rate Schedule: WEEK: $1410
Rate Schedule: 3 MOS: $12720
Rate Schedule: 6 MOS: $25440
