OROPS (Open Cab), Drum Width 48", Hydraulic Hydrostatic Drive, Warranty Chassis & Structural Components: 5 Years / 5,000 Hours, Major Components: 3 Years / 3,000 Hours, Engine: 3 Years / 3,000 Hours------Engine: Kubota D1803-CR-E5B, Tier 4 Final
Rated Power: 33 Hp @ 2,400 Rpm
Operating Weight: 6,283 Lbs
Compacting Width: 47.24 In
Drum Diameter: 28.35 In
Vibration Frequency: 63 / 67 Hz
Nominal Amplitude: 0.5 Mm
Centrifugal Force: 8,093 / 9,217 Lbf
Travel Speed: 0 – 6.2 Mph
Gradeability: 30%
Turning Radius (Inside / Outside): 7.4 Ft / 11.3 Ft
Features
Dual-Drive, Dual-Vibration System
Static Hydraulic Driving And Vibration
Hydraulic Steering
Folding ROPS
Mechanical Shock-Absorbing Seat With Seat Belt And Alarm Switch
Multi-Function Driving Handle
Combination Instrument Display (Speed, Hour Meter, Fuel Gauge)
LED Lighting
Turn Signal And Clearance Lights
Frequency Selection
5-Speed Intermittent Water Spray System
12V Power Supply
Automatic Start-Up Function
Manual And Automatic Vibration Control
Fault Alarm And Reversing Buzzer
Emergency Brake Switch
Toolkit Included
Steering Articulation Lock
Rotating Beacon
Master Power Switch
Arm Brace
Fuel Level Gauge
ROPS-Mounted Work Light
Water Tank Level Indicator
Maintenance-Free Steering Cylinder Bearings
Independent Front And Rear Vibration Control
Double Joysticks
| Weight | 6283.0 | 6283.0 |
Status: Available
Hours: 5 hrs
Weight: 6283.0
Rate Schedule: DAY
Rate Schedule: WEEK
Rate Schedule: 3 MOS
Rate Schedule: 6 MOS
