(2) 1SI 3964/ASCII Modules
(1) 1 STEP 5V/204KHz Module
(1) 1 Coul 5V/500kHZ Module
(1) 4 AI Analog Input
(3) 4 DO Digital Outputs
(5) 4 DI Digital Inputs
(1) PM-E Module
The Siemens 6ES7 151-1AA05-0AB0 is a SIMATIC DP Interface Module (IM 151-1) designed for use with the ET 200S distributed I/O system. This module provides a seamless connection between ET 200S I/O modules and a PROFIBUS DP network, enabling high-performance, decentralized automation solutions.
With support for up to 63 I/O modules, the IM 151-1 enables flexible configuration in modular systems. It features a 9-pin Sub-D PROFIBUS interface, compact DIN rail mounting, and a robust design ideal for industrial environments.
The unit supports a data volume of up to 244 bytes for both input and output, ensuring efficient data handling for a wide range of field devices. It also includes the termination module, simplifying integration and ensuring reliable communication.
| Dimensions | 19 × 10 × 7 in | 19 × 10 × 7 in |
| Weight | 8 lbs | 8 lbs |
Weight: 8 lbs
Dimensions: 19 × 10 × 7 in
