HIGH SPEED MILLING
MODEL: HSM-600
[TABLE:]
OVERALL SIZE: 850×400
T SLOTS (SIZE×NO×PITCH): 14×3×125
MAXIMUM LOAD: 350KG
TRAVEL:
X / Y / Z AXIS: 600 / 430 / 460
3 AXIS LINEAR WAY
LINEAR WAY WIDTH: 30 / 30 / 35
LINEAR WAY NUMBER: 2 on each axis
DISTANCES:
SPINDLE TO COLUMN WAYS: 480
SPINDLE TO TABLE TOP: 120~580
FLOOR TO TABLE TOP: 852
SPINDLE:
TAPER: #40
SPEED: 8000RPM
FRONT BEARING DIA.: 60
MOTOR: 5.5 / 7.5KW
AXIS MOTORS :
AXIS MOTOR TORQUE: 8 / 8 / 12Nm
MOTOR POWER: 1.6 / 1.6 / 3KW
Z AXIS BALANCE DESIGN: BRAKING MOTOR
CUTTING FEED RATE: 1-8000MM / Min
RAPID FEED RATE: 30M / 30M / 24M
MINMUM SETTING: 0.001MM
ATC:
TYPE: SWING ARM
NO. OF TOOLS: 20
MAX. TOOL (DIA / LENGTH): 125 / 250
MAX. TOOL WEIGHT: 7KG
TOOL TO TOOL/CHIP TO CHIP: 3” / 8”
BALLSCREWS:
DIA / PITCH ( X&Y AXIS ): 32×16
DIA / PITCH ( Z AXIS ): 32×16
PRECISION CLASS (C3): 0.08MM / 300MM
COOLANT & LUBR:
COOLANT MOTOR POWER: 1.27KW
COOLANT TANK VOLUME: 120L
COOLANT MOTOR CAPACITY: 20L / MIN
LUBE MOTOR POWER: 25 WATT
LUBE TANK VOUME: 2
ACCURACY:
POSITIONING: JIS 6338 : 0.005MM / 300MM, VDI 3441 : P0.015
REPEATABILITY: JIS 6338 : ±0.003MM, VDI 3441 : PS0.01
ROUNDNESS: JIS 6338 : ±0.01MM / 300MM DIAMETER
MISCELLANEOUS:
NET WEIGHT: 3400KG
POWER REQUIRED: 16KVA
PNEUMATIC REQUIRED: 7KG / CM2
