Sheet size --Width “Y”: 1.2M/ 48
Sheet size --Length “X”: 3.2 M/ 122”
Thickness range: 0.8mm to 6mm/ 0.031 to 0.250”
Table height: 660mm/26”
Cutting speed: 10 to 20 M/ min. 400 to 800”/ min
Tool cutting capacity “Z”: 2.25 square mm 0.06 x 0.06”
Z Axis min. feed: 0.01mm / 0.0004”
Sheet feed positioning Y: 0-2M/min 0 to80”/min
Sheet feed accuracy Y: 0.01mm/ 0.0004
Clamping: Pneumatic operated full length clamps
Overall width: 2200mm./ 87”
Overall Height: 2300mm/ 91”
Overall Length: 190”
Ship weight (lbs. approx.): 9MT/20,000
Motor H.P. X: 5.5
Motor HP Y: 1.3
Motor HP Z: 1.3
Compressed air: 90 psi
Voltage: 230/460/3/60Hz
