Vertical / High Efficiency
MODEL: V-32AF / AR
A.T.C: ARM
X axis travel: 800 (31.5) mm(in)
Y axis travel: 520 (20.5) mm(in)
Z axis travel: 610 (24) mm(in)
Table size (L x W): 890 x 500 (35 x 19.7) mm(in)
Max. table load: 500 kg
Spindle speed: 10000,12000 rpm
Rapid traverse X/Y/Z: 36 (1417) m/min/(ipm)
Tool storage capacity: 24 pcs
Spindle motor (30min) FANUC: 18 .5 (24.8) kW (hp)
X/Y/Z axis motor: 4/4/4 (5.4/5.4/5.4) kW (hp)
Machine size (L x W x H): 2770x2500x2730(FRONT)/2440x2765x2730(REAR) mm
Machine weight: 4700 kg
