FEATURES
Miter cutting 0°-45°
Touch screen and length encoder
Variable blade speed by motor inverter
Hydraulic blade tension device
Equipped with two vertical presses
Manual bow height setting
Vise pressure regulator
Fully automatic
Auto chip conveyor
Blade tension gauge
ITEM UNIT
Blade Motor: 5 HP
Hydraulic Motor: 1 HP
Coolant Motor: 1/6 HP
Blade Speed: 20-85 mpm
Saw Blade: 41 x 1.3 x 5330 mm (WxTxL)
Hydraulic Tank: 15 Liters
Coolant Tank: 55 Liters
Table Height: 925 mm
Weight: 1520 / 1770 kgs NW/GW
PACKING DIMENSIONS: 2750 x 2270 x 1950 mm (LxWxH)
