Dual Swivel cutting angle from 0~+-60 degrees. Can fix the position every 5 degrees.
High efficiency gear drive system cooperated to variable step pulley provides fast changing speed. Also with LED readout for clear speed figure
Heavy duty one-piece stand with swing control box for better operation.
Enlarged hydraulic cylinder and buffer spring enhance the cutting stability.
Hydraulic vise system can assist to clamp different size of workpiece properly.
Electric shut-off system and alarm.
Cleaning hose and nozzle assist in washing chips away
Easy access chip tray allows quick cleanup
Self-propelled blade brush extends the blade life
Optional selection includes laser indicator and hydraulic tension meter
ITEM: RF-330NA UNIT
Main Motor: Main Motor / 5HP Hydraulic Motor / 2HP Coolant Pump / 1/8HP HP
Speed: 60HZ / 32~96 50HZ / 26~80 Mt/min
Ft/min: 60HZ / 106~317 50HZ / 85~264
Saw Blade: 41 x 1.3 x 5890 mm (WxTxL)
inch (WxTxL): 1.61" x 0.05" x 231.88"
Machine Dimentions: 3000 x 1270 x 1730 mm (LxWxH)
inch (LxWxH): 118" x 50" x 68"
Weight: 1650 / 1860 kgs NW/GW
3635 / 4095 lbs
PACKING DIMENSIONS: 2930 x 1140 x 1981 mm (LxWxH)
inch (LxWxH): 115.3" x 44.8" x 78"
