Standard Features:
Shuttle Type Automatic Feed
3pcs Carbide blade guide system
Present cut-counter with shut-off
Power Driven Blade Brush
Nesting fixture for bundle cutting
Infinitely variable speed controlled by inverter
Hydraulic Blade Tension
PLC control for all electronic and Hydraulic functions
Work light
Automatic Chipping Conveyor Lead Screw
LED Display of Blade Speed
Check Device of Saw Blade Breaking
Flushing Hose for Machine Cleaning
Multiple Index (9 times)
Automatic Work Height Control and Fast Approach
Split Front Vise
Floating Shuttle Vise
2 M Roller Table
One Bi-Metal Saw Blade
Tool Box
Capacity
Round Bar: Dia. 400mm
Square Bar: 400x400mm
Blade size: 4880 x 41 x 1.3mm
Blade Speed: 20-100m/min.
Voltage: 415V
Weight: 2500kg
Blade Motor: 7PH
Hydraulic Pump: 1HP
Coolant Pump: 1/8 HP
