Standard Features:
Shuttle Type Automatic Feed
3pcs Carbide blade guide system
Present cut-counter with shut-off
Power Driven Blade Brush
Nesting fixture for bundle cutting
Infinitely variable speed controlled by inverter
Hydraulic Blade Tension
PLC control for all electronic and Hydraulic functions
Work light
Automatic Chipping Conveyor
Lead Screw
LED Display of Blade Speed
Check Device of Saw Blade Breaking
Flushing Hose for Machine Cleaning
Multiple Index (9 times)
Automatic Work Height Control and Fast Approach
Split Front Vise
Floating Shuttle Vise
2 M Roller Table
One Bi-Metal Saw Blade
Tool Box
Capacity
Round Bar: Dia. 550mm
Square Bar: 550x550mm
Blade size: 5980x41xT 1.3mm
Blade Speed: 20-100m/min. inverter
Voltage: 415V
Weight: 2500kg
Blade Motor: 7PH 3HP
Hydraulic Pump: 2HP
Coolant Pump: 1/4 HP
