FAGOR 8055 control
40HP servo spindle motor
Heavy duty 4-way automatic turret or Manual quick change tool post
2 speed gear change on spindle
2 - 4 jaw chuck in front/back
Back splash guard with travelling door
Rear chip conveyor (included) / front chip conveyor (optional)
6.3” diameter tailstock quill with 12” travel
2 speed quill feed
Heavy duty 30”wide bed way
32,000Lbs heavy-duty structure frame
Follow rest
Swing over bed: 1042 (41) Mm (in)
Swing over cross slide: 578 (22.75) Mm (in)
Max cutting diameter: 1016 (40.00) Mm (in)
Max cutting length: 2800 (110.24) Mm (in)
Distance between centers: 3000 (120.00) Mm (in)
Bar capacity: 10.50 In
Steady rest: 50-470 (1.96-18.5) Mm (in)
Width of bed: 755 (29.72) Mm (in)
Load capacity(between centers): 5000 (11023.11) Kgs(lbs)
TRAVEL
X axis: 540 (21.26) Mm (in)
Z axis: 2800 (110.23) Mm (in)
SPINDLE
Spindle speed range: 8-500 rpm
Spindle bore: 275 (10.83) Mm (in)
Spindle power: 40 HP
Spindle mount: A2-20
Chuck size: 25” 4 Jaw front/back in
TURRET
Number of tool stations: 4
Shank height: 40 x 40 (1.57 x 1.57) Mm (in)
FEEDRATE
X axis: 3 M/min
Z axis: 6 M/min
TAILSTOCK
Quill taper: 5 M.T.
Quill stroke: 300 (11.81) Mm (in)
Quill diameter: 160 (6.29) Mm (in)
MACHINE SIZE
Power requirement: 75 KVA / 400 V
Machine length: 6300 (248.03) Mm (in)
Machine width: 2520 (99.21) Mm (in)
Machine height: 2120 (83.46) Mm (in)
Total machine weight: 12000 (26455.47) kg (lbs)
