FEATURES
Fagor 8055 Control
Fagor Servo motor X & Z axis and Main motor
3-Jaw chuck 10” (direct mounted)
4-Jaw chuck 12” (direct mounted)
Quick change toolpost with 6-toolholder
Encoder for spindle RPM
86mm dia. Spindle Bore with D1-8 Camlock
330mm Bed width
Automatic speed change
Coolant pump
Auto lubrication
Work lamp
Safety Guard Including: Rear Splash Guard,Sliding Doors in front
[SPECIFICATIONS]
NOMINAL SIZE
Swing Over Bed: 510mm 20”
Height of Center: 255mm 10”
Swing Over Cross Slide: 305mm 12”
Distance Between Centers: 1500mm 60”
Width of Bedways: 330 mm 13 inch
HEADSTOCK
Spindle Nose Mounting: D1-8 Camlock
Spindle Bore: 86mm 3-3/8”
Taper of Spindle Bore: MT#7 (Sleeve MT#5)
Spindle Speed High: 2000-240 RPM
Spindle Speed Medium: 380-45 RPM
Spindle Speed Low: 84-10 RPM
SLIDE
Cross Slide Travel (X Axis): 280mm 11”
Dia. of Ballscrew: 25mm
Rapid Travel (X Axis): 6 m/min
Servo Motor (X Axis): 7.3N/m
Longitudinal Travel (Z Axis): 1430mm 56-1/4”
Dia. of Ballscrew: 40 mm
Rapid Travel (Z Axis): 8 m/min
Servo Motor (Z Axis): 9.3 N/m
TURRET
Max. Cutting Tools: 25 mm
TAILSTOCK
Quill Diameter: 75 mm 3”
Quill Taper: MT#5
Quill Travel: 160mm 6-5/16”
MOTOR
Main Motor: 10 HP 7.5kw
Coolant Pump: 1/8 HP 25L/min 0.4kg/cm2
WEIGHT
Machine Weight: 2300 kgs
[ACCESSORIES]
STANDARD ACCESSORIES: OPTIONAL ACCESSORIES
CNC control system: 3-jaw scroll chuck
Back plate for chuck: 4-jaw independent chuck
Coolant pump: Face plate
Automatic lubrication system: Steady rest
Work lamp: Follow rest
Safety guard: Quick change toolpost with 4 pcs toolholders
Center sleeve: Electrical 4 way toolpost
Tool box and adjusting tools: Hydraulic 8 station turret
Two dead centers: Electrical 8 station turret
Operational manual & parts list: Hydraulic chuck with draw bar & foot pedal operation
: Hydraulic tailstock
: Live center
