FEATURES
Fagor 8055i-A TC controller, 11” LCD
Fagor spindle motor 15KW Double chuck front/rear mounting- 16” SK-16 3-Jaw chuck (160mm bore) A2-11 Spindle
4” (104mm) spindle bore at 1600RPM
4 step Hyd. Shifting System for spindle Hyd.
8-Tool Turret (Taiwan) DC Servo Motor for X & Z Axes
Coolant System
18" WIDTH BED 3V Bed
6” (156mm) spindle Bore at 1000RPM
Steady Rest 50-380mm
Chip Conveyor
Full enclosure with vision window
Automatic Lubrication
Work light
Swing over bed: 670 (26.375) Mm (in)
Swing over cross slide: 380 (15) Mm (in)
Distance between centers: 2000 (80) Mm (in)
Bar capacity: 6.0 In
Steady rest: 50-380 (1.97-14.96) Mm (in)
Width of bed: 460 (18) Mm (in)
TRAVEL
X axis: 410 (16) Mm (in)
Z axis: 1800 (70) Mm (in)
SPINDLE
Spindle speeds (4 Steps): 13-1600 /11-1000 rpm
Spindle bore: 156 (6) Mm (in)
Spindle power: 15 KW
Spindle mount: A2-11
Chuck size: 16.0 in
MOTORS
X-axis servo motor output: 1.5 (2.0) KW (HP)
Z-axis servo motor output: 2.3 (3.0) KW (HP)
Coolant pump motor: 1/4 HP
FEEDRATE
X axis: 0-5 M/min
Z axis: 0-5 M/min
TAILSTOCK
Quill taper: 5 M.T.
Quill motor: FAGOR 8055 15KW (20HP)
Quill stroke: 230 (9.0) Mm (in)
Quill diameter: Ø95 (3.75) Mm (in)
Length: 5020 mm
Width: 1850 mm
Height: 2045 mm
Weight: 12500 lbs
