Fagor 8055 CNC control system
Back plate for chuck
Coolant pump
Automatic lubrication system
Center sleeve, Two dead centers
Operational manual & parts list
Tool box and adjusting tools
6" 3-jaw scroll chuck
8" 4-jaw independent chuck
Steady rest
Electrical 4 position turret
Electronic handle wheel for X/Z axis
Fully enclosed safety guard.
Chip collect tray
NOMINAL SIZE
Swing Over Bed: 356 mm 14”
Height of Center: 176mm 6-7/8”
Swing Over Cross Slide: 220mm 8-5/8”
Distance Between Centers: 1000mm 40”
Width of Bedways: 206 mm 8-1/2”
SPINDLE
Number of spindle speeds: 3 steps
Range of spindle speeds: 50 - 2000 RPM
Hole through spindle: 38mm 1-1/2in
Spindle nose: D1-4 CAMLOCK
Taper of spindle bore: M.T.#5
TAIL STOCK
Total travel of tailstock barrel: 120mm 4-3/4in
Taper in tailstock barrel: M.T.#3
Diameter of barrel: Dia. 45mm 1-3/4in
X axis
Cross slide travel: 180mm 7in
Dia. of Ballscrew: 25mm 5P
Rapid travel: 6m/min
Servo motor: 7.3Nm
Z axis
Longitudinal travel: 840mm 33-1/2in
Dia. of Ballscrew: 32mm 5P
Rapid travel: 8m/min
Servo motor: 7.3Nm
ELECTRICAL EQUIPMENT
Main Motor: 5HP 3.75kw
Auto lubrication: 3L 220V
Coolant pump: 1/8HP 220V
PACKING SIZE
Machine net weight: 1200kg
Gross weight: 1300kg
