Horizontal / Multi-function
Item: T-8M
Max. swing: 637(25) mm (in)
Max. turning diameter: STD: 285(11.2) MAX: 325(12.8) mm (in)
Max. turning length: 745(29.3) mm (in)
Bar capacity: 77(3) mm (in)
X axis travel: 225+15(8.8+0.6) mm (in)
Z axis travel: 790(31.1) mm (in)
Spindle speeds range: 3500 rpm
Chuck size: 10 in
