STANDARD ACCESSORIES
Linear scales on X,Y,Z axes
Spindle oil cooler
Automatic power off
Hydraulic system
Coolant system
Lubricator system
Alarm lamp
Work lamp
M.P.G.
RS232 interface
Heat exchanger
Leveling bolts and pads
Controller manuals and circuit diagram
Operation manuals
Machine inspection lists
Tool box
Splash guards (around the table)
SYNTEC PC Base 20MA-3E Controller
System include 10.4TFT monitor
Spindle speed 3500RPM
(Max. Gear ratio 1:8)
Oil Mist Device
OPTIONAL ACCESSORIES
X,Y,Z Axis linear scale( HEIDEHEIN,FAGOR)
Electrical Cabinet air condition device
Spindle Speed 4000RPM or 6000RPM (UHM-1210E,1512E,2016E)
Vice Controller box
Chip Conveyor & Chip Kart
Manual Rotary Table(UHM-1512E?2016E)
High Speed Tapping
[MODEL | UNIT | UHM-1210E]
TABLE / Table Size: 600X600X72D(Manual) mm
TABLE / T-Slots: 20 mm
TABLE / Maximum Load: 1500 kg
TRAVEL / X Axis: 1200 mm
TRAVEL / Y Axis: 1000 mm
TRAVEL / Z Axis: 800 mm
SPINDLE / Speed: 3500(4000,6000) rpm
SPINDLE / Taper: 7 / 24 Taper ISO.50, BT-50
DISTANCES / Spindle Center to Table: 0~1000 mm
DISTANCES / Spindle Nose to Table Center: 200~1000 mm
DISTANCES / Height from ground to table surface: 1056 mm
FEED RATE / Rapid Feed rate X/Y/Z: 15/12/15 m/min
FEED RATE / Minimum Setting: 0.001 mm
FEED RATE / Cutting Feed rate: 1~5000 mm/min
MOTOR / Spindle Servo Motor-cont./30min.: 15 HP
MOTOR / X/Y/Z/B Servo Motors: 2.9/4.4/2.9 kW
MOTOR / Lubricator Motor: 0.15 kW
MOTOR / Hydraulic Pump: 2.25 kW
MOTOR / Coolant Pump: 1.17 kW
MOTOR / Chip Conveyor: 0.2 kW
MOTOR / Oil Cooler Pump: 0.75 kW
MISCELLANEOUS / Power Required: 30 kg/cm²
MISCELLANEOUS / Pressurized Air: 6 mm
MISCELLANEOUS / Machine Weight(approx.): 7500 kg
