Features:
Fagor 8055i/plus CNC control and 11” LCD color display
Heavy-duty box way design—4 box way on Y axis
18.5/22KW spindle motor
Optional Control features included in the offer:
Built-In engraving functions: X/Y Engraving and X/A Engraving if 4th Axis installed
Automatic TOOL LENGTH CALIBRATION finds the height of the tool automatically.
Conversational to G-code programming conversion feature allows operator to program machining job without G code
Inside/outside taper threading/Boring cycle
Quick programming helical taper interpolation or helical taper threading
6,000rpm spindle speed as standard
2 speed gear driver
Spindle oil cooler
ISO50 spindle
Rigid tapping
Portable MPG
Heavily ribbed cast iron components:
4 box way on Y axis
One piece Box type base with internal rib design
Fully enclosed & heavy duty metal guarding with removable side doors
Large fully ground work table with 5 T slots
Precision ground ball screws
Heavy-duty box way design
Telescopic way covers
Automatic lubrication with low lubrication fault
Coolant ring with adjustable nozzles;
Coolant system with check valve 142Gal,1.2HP pump,27gpm@64psi
Coolant gun and air gun
Wash down system
Chip auger Conveyer with chip collector
Low voltage circuit system
Early power failure detection module
Heat exchanger for electric cabinet
EMC -SCHAFFNER Brand EMC (electromagnetic compatibility) to avoid electrical noise
Anchor kits
: Unit Description Unit METRIC S.A.E
CAPACITY / Table Diameter: Inch Mm 2250 88.58
CAPACITY / Table Height Max machining dia of job/ 2500: Inch Mm 2500 98.43
CAPACITY / Max height to be turned 1600mm 1600 62.99
CAPACITY / Table loading capacity: Lbs Kgs 10000 22000
TRAVEL / X travel Travel of TOOL HEAD, horizontal 1400mm: Inch Mm 1400 55.12
TRAVEL / Y travel travel of RAM, VERTICAL 1000mm: Inch Mm 1000 39.37
TRAVEL / Z travel travel of CROSS beam 1250mm: Inch Mm 1250 49.21
Table / steps and speed of work table 2 steps, 1 to 80 rpm(step 1: fr 1 - 9.35 - 26.7 rpm; step 2: fr 3 - 28.04 - 80rpm): ISO ISO 1 to 180 1 to 180
Table / Spindle speed: rpm rpm 1 to 180 1 to 180
Table / Spindle/table Motor: HP KW 18.5/22 25/29
Table / max torque of work table 50 knm KNm 50
MOTOR / Torque of feeding servo motor 26 Nm
MOTOR / Motor for BEAM lifting up or down 11 kW 11 14.67
MOTOR / Rapid traverse speed: 400 mm/min
MOTOR / Motor of beam up/down: 11 kW (2 shafts out)
Ram / Servo motor for feeding in left & right: 62 Nm 50
Ram / Servo motor for vertical toolpost (with brake):62 Nm
Ram / max cutting force of TOOL HEADS: 30 kn 30
Ram / size of cross raM, section 220 × 220 mm 220 × 220 8.66 x 8.66
Ram / SIZE OF TOOL: 40 × 40 mm: Inch Mm 40 × 40 1.57 x 1.57
Ram / Max swivelling angle of HEAD ±300 ±30 ±30
Ram / Cutting force of head: 35 kN: Inch Mm
Ram / Total cutting force: 53 kN: Inch Mm
Performance / Rapid travel of head: 8000 mm/min: IPM MPM 8.0 315
Performance / traverse speed of beam 400mm/min: IPM MmPM 400 15.75
Performance / Feed Rate X/Y/Z range of feed for turrets automatic mm/min: IPM MmPM 0.1 – 2000 mm/min 0.01-196.9
Performance / Positioning accuracy: Inch Mm 0.005 0.0002
Performance / Repeatability: Inch Mm 0.005 0.0002
Dimensions / Length x Width x Height: Inch CM 536×460×537
Dimensions / Weight: Lbs Kgs 38,000
