Heavy Duty Vertical Lathes
• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.
Model: VL-1000ATC Unit
Max. Swing Dia.: Ø1350 mm
Max. Turning Dia.: Ø1150 mm
Max. Turning Height: 1070 mm
Main Spindle Motor: 37/45 kw
Machine (L1): 4600 mm
Machine (W1): 5500 mm
Machine (H1): 5330 mm
Machine Weight: 24000 kg
