VL-1000ATC+C+APC

VL-1000ATC+C+APC

Overview
Type:
Vertical Boring Mills (incld VTL)
Model:
VL-1000ATC+C+APC
Description

Heavy Duty Vertical Lathes
Multi-function Machining
Equipped with a second power spindle, the C and CF axes provide turning, face milling, side milling, drilling, grinding and tapping operations all in a single set-up.
Improving the set-up time and overall efficiency by adding an automatic pallet changer to your heavy duty vertical lathe.

Specifications

Model: VL-1000ATC+C+APC Unit
Max. Swing Diameter: Ø1350 mm
Max. Turning Diameter: Ø1150 mm
Max. Turning Height: 800 mm
Main Spindle Motor: 37/45 kw
Machine (L1): 6500 mm
Machine (W1): 7300 mm
Machine (H1): 5330 mm
Machine Weight: 30000 kg
