Dual-head design: This design enables notching in one head and edge punching in another head.
Control system: Centralized control box with remote foot switch provides single, inch and continuous stroking operation.
Fine adjustment: A good scale for small materials positioning with a fine adjustment on X-axis and stop Y-axis is provided.
Material holder: In order to prevent deviation during cutting, this material holder can hold the material while lowering the blades.
CAPACITY (MM): 6.4
MAX. NOTCH (MM): 254 X 254
EDGE NOTCH (MM): 100 X 150
RAM STROKE (MM): 38
STROKE (SPM): 21
MOTOR (HP): 5
WEIGHT (KG): 1300
WEIGHT (KG): 2413 X 914 X 1448
