Dual-head design: This design enables notching in one head and edge punching in another head.
Control system: Centralized control box with remote foot switch provides single, inch and continuous stroking operation.
Fine adjustment: A good scale for small materials positioning with a fine adjustment on X-axis and stop Y-axis is provided.
Material holder: In order to prevent deviation during cutting, this material holder can hold the material while lowering the blades.
CAPACITY (MM): 4.0
MAX. NOTCH (MM): 220 X 220
EDGE NOTCH (MM): 50 X 100
RAM STROKE (MM): 25
STROKE (SPM): 18
MOTOR (HP): 2
WEIGHT (KG): 920
SIZE (MM): 1549 X 533 X 1219
