STANDARD EQUIPMENT:
Two axis back gauge
One axis CNC control: X – axis
One axis manual adjustment: R – axis
Fully equipped with Masteel tooling and clamping system
Floating-adjustable die clamping system for various die applications
Hardened and precision ground tool steel gooseneck punch: 53-58RC;100Ton/M(33Ton/Ft) capacity
Hardened and precision ground Masteel 8 openings, 4-way die: HB190-260
2 - Front support arms
OPTIONAL EQUIPMENT: CNC R axis , Central lubrication, Safety light curtain Interlock Back Guard, Quick- set front sheet support (2 SETS) Special top and bottom tools, Special throat depth (500,600 and 750 mm) 440 or 600V Electrical, Laser protection system for die area Hydraulic oil coolant, WILA Manuel Anti-Deflection system Nema 12 Electrical Cabinet w/ Thermal Breaker Disconnect WILA Hydraulic top and bottom tool holding system WILA Anti-Deflection System which operates automatically with DNC unit according to tonnage applied Multi axis control: R, Z1, Z2 up to 6 axis
Max. Capacity Tons: 60
Max. Bending Length: 5'
Distance between Frames: 50.4"
Height of Bed: 34"
Depth of Throat: 10.24"
Length of Ram Stroke: 6.5"
Fast Approach Speed IPM: 275
Press Speed IPM: 25
Fast Return Speed IPM: 245
Max. Open Height: 16.1"
Main Motor: 10
Back gauge Travel: 28"
Weight Lbs: 7716
Dimensions L x W x H: 65 x 51 x 92
