The Clausing Drill Press is a high-precision industrial drill press built for toolroom accuracy and long service life. Known for its smooth variable-speed operation and rigid column structure, this machine delivers consistent drilling performance in steel, aluminum, and cast materials. Clausing’s American-built drill presses are widely used in repair shops, fabrication facilities, R&D labs, and production environments requiring reliable, repeatable hole making.
Featuring a large working surface, precision-ground quill, and a fully adjustable table, the Clausing drill press provides exceptional control over feed, speed, and hole quality. The variable-speed drive allows rapid adjustments without belt changes, while the quill feed lever and depth stop provide smooth operation for tapping, boring, and precision drilling work.
Features & Options
Variable-speed drive for fast spindle rpm adjustment
6″ quill travel for deep-hole drilling
Heavy-duty head and column for precision and rigidity
Tilting production table with large working surface
MT3 or R8 spindle taper for tooling flexibility
Positive depth stop for repetitive drilling
Built for toolroom, maintenance, and production environments
Optional power feed and tapping controls
Specifications are typical for Clausing 20″ drill press models. Actual details vary by configuration. Always verify with the machine nameplate or original documentation.
Manufacturer: Clausing
Model: 20″ Variable-Speed Drill Press
Machine Type: Floor Drill Press
Drilling Capacity (Steel): 1″
Throat Capacity: 20″
Spindle Taper: MT3 or R8
Spindle Travel: 6″
Spindle Speed Range: 500–4,000 rpm
Motor Power: 1.5–2 hp (1.1–1.5 kW)
Table Size: 14″ × 14″ tilting table
Column Diameter: 4″
Distance Spindle to Table: Up to 29″
Machine Weight: ~600 lb (272 kg)
Final Listing Price: Request Quote
