USED 1966 PINES #2 HYDRAULIC ROTARY-DRAW BENDER
Overview
The 1966 Pines Hydraulic Pipe Bender (Model #2) is a heavy-duty rotary-draw bender designed for consistent and repeatable bending of pipe and tubing. Built with a hydraulic mandrel extractor, automatic turret stops, and robust frame construction, this machine remains a staple in fabrication, aerospace, shipbuilding, and industrial bending applications. With a 2″ IPS schedule 80 pipe capacity, the Pines #2 combines flexibility and durability, providing decades of dependable service.
Features & Options
Hydraulic rotary-draw bending action
2″ IPS schedule 80 pipe bending capacity
Hydraulic mandrel extractor
Automatic 8-position turret stop system
Counter-clockwise bending orientation (typical)
Pushbutton operator console
Overbend compensation for springback
Multiple die sets for pipe and tubing (if equipped)
Heavy-duty frame and hydraulic drive for durability
Specifications may vary depending on configuration. Verify with Pines nameplate or machine records.
Specs
Year: 1966
Manufacturer: Pines
Model: #2 Hydraulic Rotary-Draw Bender
Machine Type: Hydraulic Tube & Pipe Bender
Pipe Capacity: 2″ IPS Schedule 80
Tube Capacity (Non-Ferrous): Up to 3½″ OD × 0.120″–0.188″ wall
Maximum Bend Radius: 12″
Maximum Bend Angle: 180° + overbend
Maximum Tube Length Over Mandrel: 89″ (7′ 5″)
Bend Arm Speed: ~6 RPM
Hydraulic System Pressure: ~2,000 PSI
Main Motor: 10 hp
Turret / Stops: Automatic 8-position turret stop
Controls: Pedestal-mounted pushbutton console
Machine Weight: ~6,000 lb
Final Listing Price: Request Quote
