Working Height: 45 ft Platform Height: 39 ft Stowed Height: 4 ft 8 in Platform Platform Dimensions: 7 ft 5 in × 3 ft 10 in Extended Deck Length: 3 ft (slide-out) Guardrail Height: 3 ft 7 in Dimensions & Weight Length (stowed): 8 ft 2 in Length (extended): 10 ft 5 in Width: 3 ft 11 in Ground Clearance: 4 in (center), 0.75 in (with pothole guards deployed) Wheelbase: 6 ft 1 in Operating Weight: 7,100–7,185 lb Capacity & Performance Maximum Lift Capacity (Platform): 770 lb Maximum Capacity (Extended Deck): 250 lb Occupancy: 3 persons Drive Speed (Stowed): 2 mph Drive Speed (Raised): 0.5 mph Gradeability: 25% Turning Radius (Inside): 0 in Turning Radius (Outside): 7 ft 7 in Raise/Lower Time: 71 sec up / 41 sec down Power & Controls Power Source: 24 V DC (4 × 12 V, 150 Ah batteries) Hydraulic Capacity: 7.5 gal Controls: Proportional Drive & Lift Tires: 15 × 5 in (solid non-marking)
| Weight | 7100.0 | 7100.0 |
Status: Available
Weight: 7100.0
Rental Rate: $2030
Rate Schedule: DAY: $304
Rate Schedule: WEEK: $680
Rate Schedule: 3 MOS: $6090
Rate Schedule: 6 MOS: $12180
