Tractor w/Front End Loader and Backhoe w/Bucket-------
Model: Yanmar 3TNV76F (Tier 4 compliant)
Type: 3-cylinder, indirect-injection, water-cooled diesel
Displacement: 68.0 cu in
Gross Engine Horsepower: 21.5 HP
PTO Horsepower: 15.0 HP
Rated Speed: 3,000 RPM
Fuel Tank Capacity: 6.6 gallons
Alternator: 12V – 40A
Drive Train
Transmission: 2-range hydrostatic drive
Brakes: Wet, multi-disc
Steering: Hydrostatic power steering
Drive: 4WD
PTO (Power Take-Off)
Type: Independent
Rear PTO: 540 RPM
Mid PTO: 2,500 RPM
Hydraulics
Implement Pump Flow: 4.6 GPM
Steering Pump Flow: 2.1 GPM
Total Hydraulic Flow: 6.7 GPM
3-Point Hitch
Category: I
Lift Capacity at Hitch Ends: 970 lbs
Lift Capacity at 24" Behind Hitch: 728 lbs
Lift Control Type: Position control
Dimensions & Weight
Overall Length: 97 inches
Wheelbase: 56 inches
Minimum Width with Industrial Tires: 47 inches
Height to Top of ROPS: 87 inches
Weight: Approximately 1,433 lbs
Loader Compatibility
Compatible Loader: LL1700
Lift Capacity at Pivot Pin: 980 lbs
Maximum Lift Height: 74 inches
Clearance with Attachment Dump: 55 inches
Overall Height in Carry Position: 41 inches
Breakout Force at Pivot Pin: 1,470 lbs
| Weight | 2200.0 | 2200.0 |
Status: Available
Hours: 152
Engine Power: 0.0
Weight: 2200.0
Rental Rate: $3000
Rate Schedule: DAY: $450
Rate Schedule: WEEK: $1000
Rate Schedule: 3 MOS: $9000
Rate Schedule: 6 MOS: $18000
Attachment: General Purpose Bucket
