General & Performance Specs
Engine: 4-cylinder diesel (e.g. Kubota V2607 / Bobcat D24 depending on spec)
Power: ~ 66 hp (49.2 kW)
Displacement: ~ 2392–2600 cm³ (≈ 2.4–2.6 L)
Fuel tank capacity: ~ 138.2 L
Rated operating capacity (35% tipping load, ISO): ~ 971 kg (≈ 2140–2200 lb)
Tipping load (ISO): ~ 2774–2834 kg (≈ 6,000–6,250 lb) depending on spec / region.
Hydraulic pump flow (standard): 64.7 L/min (≈ 17.1 gal/min)
Hydraulic pump flow (high-flow option): up to 101.1 L/min
Hydraulic relief pressure (quick-couplers): ~ 23.8–24.5 MPa (≈ 3,500 psi)
Travel speed: up to ~ 16.7 km/h (≈ 10.4 mph) with optional high-speed drive.
⚙️ Weight, Size & Dimensions
Operating weight: ~ 3,500–3,600 kg (≈ 7,700–7,900 lb) depending on version.
Width (over tracks): ~ 1.70 m (≈ 67 in)
Length (with bucket): ~ 3.38 m (≈ 133 in)
Height (top of cab / ROPS): ~ 1.98 m (≈ 77.8 in)
Bucket width: ~ 1.73 m (≈ 5.68 ft)
Bucket capacity: ~ 0.93 m³ (≈ 246 gallons equivalent)
