OROPS, (Open Cab), Blade, Auxillary Hydraulics, Quick Coupler, Hydraulic Thumb, Bucket | Additional Buckets & Compaction Wheel Available For Sale ||| Engine: Kubota V2403-M-DI-E3B-BC-5, 4-cylinder diesel
Horsepower: 42.7 hp @ 2,200 rpm
Torque: 152.7 Nm @ 1,400 rpm
Emissions: Tier 4 compliant
Operating Weight: 10,077 lbs
Bucket Digging Force: 7,650 lbf
Arm Digging Force: 5,332 lbf
Rated Lift Capacity: 5,131 lbs @ 118 in radius
Travel Speed:
Low: 1.5 mph
High: 2.6 mph
Ground Pressure: 3.8 psi
Dimensions
Transport Length: 210.8 in
Width: 77.2 in
Height (Top of Cab): 99.7 in
Track Width: 11.8 in
Tail Swing Type: Zero Tail Swing
Digging Capacities
Maximum Dig Depth: 10.8 ft
Maximum Reach at Ground Level: 18.6 ft
Maximum Dump Height: 11.9 ft
Boom Swing:
Left: 75°
Right: 50°
Hydraulic System
Auxiliary Flow: 20 gpm
Auxiliary Pressure: 3,045 psi
Pump Type: Variable displacement, load-sensing piston pump
Features & Options
Standard:
Auto idle
Selectable auxiliary hydraulic flow
Rubber tracks
Quick Tach system
Fingertip boom swing control
Optional:
Cab with heat and air conditioning
Angle blade
Hydraulic clamp
Secondary auxiliary hydraulics
Steel tracks
various buckets and compaction wheel for additional fees No access in pull down for my specifics please modify
| Weight | 11111.0 | 11111.0 |
Status: Available
Hours: 750
Weight: 11111.0
Rental Rate: $3800
Rate Schedule: DAY: $570
Rate Schedule: WEEK: $1267
Rate Schedule: 3 MOS: $11400
Rate Schedule: 6 MOS: $22800
Attachment: Bucket 18in
Attachment: Bucket 24in
Attachment: Bucket 36in
Attachment: Compaction Wheel
