Performance: Maximum Lift Capacity: 12,000 lbs (5,443 kg) Maximum Lift Height: 56' 3" (17.14 m) Maximum Forward Reach: 42' 6" (12.95 m) Rated Lift Capacity at Max Height: 6,000 lbs (2,722 kg) without outriggers; 7,000 lbs (3,175 kg) with outriggers Rated Lift Capacity at Max Reach: 1,000 lbs (454 kg) without outriggers; 3,500 lbs (1,588 kg) with outriggers Dimensions: Overall Length (less forks): 23' 1" (7.03 m) Overall Height (stowed): 8' 6" (2.59 m) Overall Width: 8' 5" (2.56 m) Ground Clearance: 19" (48.26 cm) Turning Radius (outside): 173" (4.39 m) Engine: Model: Deutz TCD 3.6L Tier 4 Final Power Output: 107 hp (80 kW) Max Torque: 320 lb-ft (434 Nm) Operational: Operating Weight: 36,625 lbs (16,613 kg) Drawbar Pull: 22,500 lbs Max Travel Speed (forward): 15 mph (24 km/h) Transmission and Axles: Transmission Type: Dana Powershift, 3 speeds forward/reverse Axles: Dana Steering Modes: Front Wheel 4 Wheel Crab Steering Tires: Standard: Foam-Filled 14 x 24 16PR Grip Lug Capacities: Fuel Tank: 35 gallons (132 L) Hydraulic Reservoir: 43.85 gallons (166 L)
| Weight | 32000.0 | 32000.0 |
Status: Available
Weight: 32000.0
Rental Rate: $6250
Rate Schedule: DAY: $938
Rate Schedule: WEEK: $2350
Rate Schedule: 3 MOS: $18750
Rate Schedule: 6 MOS: $37500
