USED 2018 DAVIS STANDARD sheet line

Capacity:
Extruder sized x 1,700 lb/hr
Downstream sized for 2,500 lb/hr (Assumes addition of co-ex capacity)
This line has fewer than 6000 hours of run time
this line was designed to run primarily lldpe and some pp structures with metal fibers (pre-compounded)
13-25 mil thick

Extruder 6.0” 30:1 L/D Air Cooled non-vented Thermatic III
500 HP (370 kw) AC Yaskawa Drive/Reliance motor
DSBM Barrier Screw C83.
Ball & Transfer Pivot with track to move Extruder and facilitate screw extraction.

DS Epic Control Syst with elapsed time meter. 6 Heat/Cool zones, 12 Heat only.

Mahlo thickness gauging system included

54” Allied Dies Inc Die with cart & platform
External deckles 6” per side
For up to 1700 lb/hr or 2500 lb/hr
Lip opening : 0,001-0.040”
Gauge range: 13-25 mils
ran lldpe with metal fibers

78” XP Express Roll Stand
3 x 24” (609 mm) diameter cooling rolls
TCU under conveyor
25 ft long roll-over conveyor.
Edge trim assembly
Pull roll assembly.

Rapid Edge trim granulation Syst

70” Turret Winder with Auto cut & transfer
2 Winding shafts
Accumulator
Winder designed to control differential winding if required
Max 40” roll diameter

Material conveying equipment
TSM Vacuum loader with 2,5” pickup wand
Operator platform.
Vacuum pump 10HP
Central filter assembly

Spare screw with Colmonoy 83 flights & Chrome plating included
Spare Barrel with Tungsten carbide bi-metallic cast-on liner X-800 included

located in Greater Chicago area
Can be demonstrated under power with advance notice.

Buyer to dismantle and load

Approximate foot print of this line is 95' x 21' (29m x 6.5m)

New Price, Must move.
