Designed for heavy and interrupted cutting with superior part finishes.
• True 30-Degree Slant Bed
• Live Tooling
• Hydraulic Actuated 18” 3-Jaw Chuck
• Fanuc® Oi-TF Control
• Hardened and Ground Box Ways on All Axes
• Double Nut, Pretensioned Ballscrews
• Hand-Scraped Contact Areas
• 12 Station Bi-Directional Hydraulic Turret
• BMT65 Tooling Turret
• Tailstock Body Mounted on Hardened Box Ways with Hydraulic Quill
| # Axis | 2 | 2 |
| Chuck Size | 18" | 457.2 mm |
| Power | 24.8 hp | 18.5 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Control | CNC (FANUC 0i-TF) | CNC (FANUC 0i-TF) |
Configuration: Box-Way Lathe with 18" Chuck
Travels: 11.8x, 49.2z in
Spindle Speed & Torque: 6000 rpm | 365 ft-lbs
Spindle Power: 24.8 hp
