USED MORI SEIKI SH-403

The Mori Seiki SH-403 is a compact, high-speed horizontal machining center designed for multi-face machining and precision production work. With twin automatic 15.7″ (400 mm) pallets and travels of 22″ (X), 24″ (Y), and 24″ (Z), it allows continuous operation through automatic pallet exchange, maximizing productivity. The machine’s rigid construction and 40-taper spindle design ensure excellent stability and surface finish across a wide variety of materials.
Equipped with a powerful 25 hp (18.5 kW) spindle motor delivering speeds up to 12,000 rpm, the SH-403 provides both torque for roughing and speed for finishing. The 60-tool automatic tool changer and Fanuc-based Mori MAPPS CNC control deliver flexibility and reliability for production environments. Known for its precision and durability, the SH-403 remains a proven choice for automotive, aerospace, and general machining applications.
Features & Options
Dual 15.7″ automatic pallets for continuous operation
CAT-40 spindle with 12,000 rpm capability
22″ × 24″ × 24″ axis travels
60-tool automatic tool changer
25 hp high-torque spindle motor
Fanuc / Mori MAPPS CNC control
Through-spindle coolant and chip management system
Compact, high-rigidity design ideal for production
Specifications may vary depending on configuration and year of manufacture. Always verify with Mori Seiki factory documentation or nameplate.

Manufacturer: Mori Seiki
Model: SH-403
Machine Type: Horizontal Machining Center
Number of Pallets: 2 (Automatic Pallet Changer)
Pallet Size: 15.7″ × 15.7″
X-Axis Travel: 22″
Y-Axis Travel: 24″
Z-Axis Travel: 24″
Spindle Taper: CAT-40
Spindle Speed: 12,000 rpm
Spindle Motor: 25 hp
Tool Changer: 60 ATC
Control: Fanuc
Rapid Traverse: 1,260 ipm
Machine Weight: ~19,800 lb
Final Listing Price: Request Quote
