The 2005 Weiler E50 is a high-precision CNC turning lathe designed for demanding toolroom and production work. With a swing over bed of approximately 20″ (500 mm) and 40″ (1,000 mm) between centers, it provides excellent versatility for machining shafts, bushings, and precision components. The machine features a rigid cast-iron bed, hardened guideways, and precision ball screws for smooth and accurate motion.
Equipped with a Fanuc or Siemens CNC control, the E50 allows both conversational and G-code programming, making it ideal for prototype or small-batch production. Its robust 20 hp main spindle motor delivers up to 3,000 rpm, while the precision tailstock supports long workpieces. The E50 continues Weiler’s legacy of combining German engineering with practical operation, ensuring stability and accuracy across all turning applications.
Features & Options
20″ swing with 40″ between centers for versatile turning
High-rigidity cast-iron construction
3.15″ spindle bore and 3,000 rpm maximum speed
Fanuc or Siemens CNC control
Precision-ground guideways and ball screws
Tailstock for long workpiece support
Compact footprint for toolroom or production environments
Excellent for precision and prototype machining
Specifications are based on typical 2005 Weiler E50 configurations. Always verify with the machine’s nameplate or factory documentation.
Year: 2005
Manufacturer: Weiler
Model: E50
Machine Type: CNC Precision Lathe
Swing Over Bed: 20″ (500 mm)
Swing Over Cross Slide: 12″ (300 mm)
Distance Between Centers: 40″ (1,000 mm)
X-Axis Travel: ~10″ (250 mm)
Z-Axis Travel: ~40″ (1,000 mm)
Spindle Bore: 3.15″ (80 mm)
Spindle Speed: Up to 3,000 rpm
Spindle Motor: ~20 hp (15 kW)
Tailstock Quill Diameter / Travel: ~3.9″ / 6″ (100 / 150 mm)
Control: Fanuc or Siemens CNC
Machine Weight: ~9,000 lb (4,000 kg)
Final Listing Price: Request Quote
