USED 1997 FADAL VMC-20

The 1997 Fadal VMC-20 is a precision vertical machining center designed for toolroom, prototype, and production applications. With travels of 20″ × 16″ × 20″, a rigid CAT-40 spindle taper, and spindle speeds up to 7,500 rpm, it offers flexibility for a variety of milling operations. The 16-station automatic tool changer and Fadal 88HS CNC control provide efficient cycle times and dependable accuracy. Compact yet powerful, the VMC-20 is well-suited for shops seeking reliable performance in a small footprint.
Features & Options
CAT-40 spindle with up to 7,500 rpm
16-station automatic tool changer
Fadal 88HS CNC control system
20″ × 16″ × 20″ travels for compact part machining
Rigid cast-iron frame construction
Automatic lubrication and coolant system
Rapid traverse at 400 ipm
Compact footprint for toolrooms and small shops
Optional 4th axis capability
Specifications may vary depending on machine configuration. Verify with Fadal nameplate or build sheet.

Year: 1997
Manufacturer: Fadal
Model: VMC-20
Machine Type: Vertical Machining Center
X-Axis Travel: 20″
Y-Axis Travel: 16″
Z-Axis Travel: 20″
Table Size: 29.5″ × 16″
Max Table Load: ~750 lb
Spindle Speed: Up to 7,500 rpm
Spindle Taper: CAT-40
Spindle Motor: 7.5 hp
Tool Changer: 16-station carousel
Control: Fadal 88HS CNC
Rapid Traverse: 400 ipm
Machine Dimensions: ~75″ × 77″ × 92″
Machine Weight: ~6,200 lb
Final Listing Price: Request Quote
