Used Union TX-200 triplex pump fluid end only with the following features:
• 5" stroke
• 200 HP
• #1.5 steel fluid end
• 1.312" plungers
• 3" 300# RF suction connection
• 2" 2500# RTJ discharge connection
• Weight
• Dims
Applications: Water Jetting Pump, Pressure Testing Pump, Well Service Pump, Water Transfer Pump, Pressure Washer Pump, Paint Stripping Pump, Hydro Blasting Pump, Car Wash Pump, Hydrotesting Pump, Hydrostatic Testing Pump, Mud Pump, Kill Truck Pump, Lift Station Pump, Condensate Pump, Cooling Tower Pump, Geothermal Pump
HP: 200
RPM: 369
PSI: 5000
GPM: 95
BPD: 3257
BPD: 3257
BPH: 135.7
BPM: 2.26
L/SEC: 5.99
L/MIN: 360
M3/SEC: 0.006
M3/HR: 21.58
M3/DAY: 518
