6-Axis Industrial Robot with Lathe Machine Tending Tooling
| # Axis | 6 | 6 |
| Payload | 20 kg | 44.1 lb |
| Horizontal Reach | 1,725 mm | 67.913" |
| Vertical Reach | 3,078 mm | 121.18" |
Request a Quote
Add to Cart
Payload: 20 Kg
Reach: 1725 mm
Repeatability: +/-0.04 mm
Robot Weight: 230 Kg
Mounting: Floor or Ceiling
Series: R-Series
JT1: +/-180° @190°
JT2: +155°/-105° @205°
JT3: +150°/-163° @210°
JT4: +/-270° @400°
JT5: +/-145° @360°
JT6: +/-360° @610°
Wrist Moment JT4: 45 Nm
Applications: Material Handling / Machine Tending / Deburring / MIG/TIG Welding / Laser Cutting
Lathe Machine Tending Tooling
