Toyooki Kogyo Co Ltd HD3-2S-BCA-025B-WYD2 Directional Hydraulic Solenoid Valve [New]

Max Operating Pressure (MPa): 25. Spool Type: BCA (Spring Offset). Nominal Size: 025, Conforming to ISO 4401-03-02-0-94. Wiring Method: Cable Connection to the Side of the Terminal Box. Voltage Indication: 24 VDC. Toyooki Kogyo Co Ltd HD3-2S-BCA-025B-WYD2 Directional Hydraulic Solenoid Valve - SPECIFICATIONS: Series: HD. Max Operating Pressure (MPa): 25. Spool Type: BCA (Spring Offset). Nominal Size: 025, Conforming to ISO 4401-03-02-0-94. Design Code: B. Wiring Method: Cable Connection to the Side of the Terminal Box. Voltage Indication: 24 VDC. Option FUnctions: None. Type: High Pressure Type. Power Source: DC. Surge Absorber: Diode. Compatibility to DeviceNet: Yes - NOTE: Select the slave unit carefully since the solenoid current value is high.. Toyo-Oki. Toyooki Kogyo Co Ltd. HD3-2S-BCA-025B-WYD2.
