| X | 41.34" | 1,050 mm |
| Y | 35.43" | 899.92 mm |
| Z | 38.58" | 979.93 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 60 | 60 |
| Taper | CAT-50 | CAT-50 |
| Pallet-W | 24.8" | 629.92 mm |
| Pallet-L | 24.8" | 629.92 mm |
| # Axis | 4 | 4 |
| Control | CNC (Mazatrol Matrix Nexus) | CNC (Mazatrol Matrix Nexus) |
| Dimensions | 143.11″ × 267.56″ x 133.86″ High | 143.11″ × 267.56″ x 133.86″ High |
| Weight | 41,887 lbs | 41,887 lbs |
All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.
Features:
Mazatrol Matrix Nexus CNC Control
Full 4th Axis
24.8" x 24.8" Twin Pallet Changer
Rigid Tapping
Coolant System
Travels:
X-Axis Travel: 41.34″
Y-Axis Travel: 35.43″
Z-Axis Travel: 38.58″
B-Axis: 0.001° Indexing
Spindle Nose to Table Center: 3.94″ – 42.52″
Pallet Top to Spindle Center: 3.94″ – 39.37″
Rapid Traverse (X/Y/Z): 2,362 Inches Per Minute
Cutting Feedrate (X/Y/Z): 2,362 Inches Per Minute
Pallet:
Number of Pallets: 2
Pallet Size: 24.8″ × 24.8″
Maximum Workpiece Diameter: 41.34″
Maximum Workpiece Height: 51.18″
Maximum Pallet Load: 3,307 lbs
Pallet Change Time: 10 Seconds
Index Time: 1.9 Seconds / 90°
Spindle:
Spindle Speed: 8,000 RPM
Spindle Taper: CAT-50
Spindle Power: 50 HP
Automatic Tool Changer:
Tool Capacity: 60 Tools
Max Tool Diameter (With Adjacent Tools): 4.92″
Max Tool Diameter (Empty Adjacent): 9.84″
Max Tool Length: 24.8″
Max Tool Weight: 66 lbs
Chip-to-Chip Time: 4.2 Seconds
General:
Air Requirement: 100 psi 4 scfm
Power Requirement: 82.51 kVA / 3-phase / 60 Htz
Machine Dimensions: 143.11″ × 267.56″ x 133.86″ High
Machine Weight: 41,887 lbs
8,000 RPM Spindle Option Available
50-Taper Integral Motor Spindle
60 Station Automatic Tool Changer
EIA Inspection Plus Probing Software
Mazak Monitoring System B – Optical OMP60 Probe
Mazak Super Flow T8 (1,000 PSI)
MPG Handwheel Control
Chip Conveyor
Books & Manuals
