GMC 8' x 10ga HYDRAULIC SHEAR

NEW "GMC" HYDRAULICALLY OPERATED SHEAR
MODEL: HS-0810MD
CUTTING CAPACITY:
MILD STEEL: 8' x 10 ga
STAINLESS STEEL: 8' x 14 ga
BLADE LENGTH 8' 2"
SPRING HOLD DOWNS
STROKES PER MINUTE ADJUSTABLE 14-18
WORKTABLE HEIGHT 30-1/2"
FRONT SUPPORT ARM 24"
REAR OPERATED MANUAL BACKGAUAGE 26"
BLADE RAKE ANGLE 1.5°
OIL TANK CAPACITY 20 GALLONS
MAIN MOTOR 7.5 HP/220-440/3/60
WEIGHT 5,650 LBS (APPROX.)
DIMENSIONS 118" x 36" x 52"

EQUIPPED WITH:
60" SQUARING ARM
(2) 24" FRONT SUPPORT ARMS
WORK LIGHT/SHADOW LINE
FINGER GUARD
REMOTE FOOT PEDAL

OPTIONAL EQUIPMENT:
-SAFETY FENCE FOR ENCLOSURE OF THE BACK SIDE OF THE MACHINE
-SPECIAL BLADE SET FOR STAINLESS STEEL
