GMC 5' x 55 TON PRESS BRAKE CNC

New "GMC" 55 Ton Hydraulic Press Brake
HPB-5505CNC

Features:
ISO 9001 certified
Meet OSHA and CE safety standard
Delem 41, 2 Axis CNC back gauge
Tool Library
Programmable Angle/ Angle Correct
Germany Rexroth hydraulic system
Yaskawa Servo motor and Drives
Schneider electrical components
All steel construction for maximum rigidity
Hydraulic logic system centrally located and quiet
Safety type foot pedal with handle and E-stop switch
Safety 24V low voltage & overload protection
One year industrial warranty for parts

Specifications:
Maximum Pressure 55 tons
Bending Length Capacity 63" (5'3")
Distance between Upright (housing) 49-1/2"
Ram Stroke Travel 6"
Cylinder Travel Adjustment, Max 2-1/2"
Table Width 6"
Distance between Table and Ram 15"
Throat Depth 10"
Back Gauge Distance 24"
Back Gauge Repeatability .0039"
Y Axis Repeatability .0039"
Approach Speed, Inch/ Second 3.54"
Working Speed, Inch/ Second 0.78"
Return Speed, Inch / Second 2.75"
Main Motor 7-1/2 HP, 220V, 3-phase
Servo Motor for Back Gauge 1 HP, 220V, 3-phase
Servo Motor for Bending Angle Setting 1/2 HP, 220V, 3-phase
Hydraulic Oil Tank Capacity 38 Gallon
Machine Weight 7,150 lbs.
Machine Size 90" x 61" x 87"

OPTIONAL EQUIPMENT:
Custom Tooling, Made in the USA
Single V Die Holder
On-site training
