| Weight | 450 LBS. (APPROX.) | 450 LBS. (APPROX.) |
NEW "FLAGLER" 20 Ga. HIGH SPEED PITTSBURGH
CAPACITY 20-26 Ga. (MILD STEEL)
DEPTH OF POCKET 5/16" WIDTH. PITTSBURGH LOCK USES APPROX. 1" OF MATERIAL
EXTENDED SHAFTS FOR 1 SET OF AUX. TOOLING
SPEED 100 FPM (APPROX.)
MOTOR 3 HP /230-460/3/60 1,800 RPM
DRIVE MATCHED DOUBLE V BELT
BASE ARC WELDED STEEL. HEAVY TOP PLATE
DIMENSIONS 36" x 16-1/2" x 37"
FEED TABLE HEIGHT 32-5/8"
WEIGHT 450 LBS. (APPROX.)
***SHOWN WITH OPTIONAL SHORT PARTS FEEDER***
AUXILIARY TOOLING AVAILABLE:
3/8" DOUBLE SEAM ROLLS
1 1/8" DRIVE CLEAT ROLLS
3/8" RIGHT ANGLE FLANGE
IDEAL FOR MEDIUM TO LARGE SIZED SHEET METAL CONTRACTORS.
BUILT ON THE SAME FRAME AS THE FLAGLER 16ga. PITTSBURGH MACHINE,
MAKES THIS THE MOST ROBUST 20ga PITTSBURGH ON THE MARKET.
THIS MACHINE FEATURES HARDENED FEED GAUGES AND 3 PIECES SHAFT/ROLL/GEAR DESIGN.
