| Weight | 200 LBS. (APPROX.) | 200 LBS. (APPROX.) |
NEW "FLAGLER" HEMMED COLLAR MACHINE
CAPACITY 24ga AND LIGHTER
SIZE 5" MIN. DIAMETER. 18" MAX. DIAMETER. 2-1/8" BLANK, 1/8" HEM.
SPEED 70 FPM (APPROX.)
MOTOR 1/2 HP /110/1/60/ 1,800 RPM.
DRIVE V BELT
BASE ARC WELDED STEEL
DIMENSIONS 34" L x 16" W
WEIGHT 200 LBS. (APPROX.)
THIS MACHINE IS USED FORM FORMING A SAFETY EDGE HEM AND
COIL THE BLANKS COMMONLY USED FOR BOOTS AND FITTINGS
