| Weight | 750 LBS. (APPROX.) | 750 LBS. (APPROX.) |
NEW "FLAGLER" SPIN COLLAR MACHINE
CAPACITY 24 Ga. AND LIGHTER
SIZE 5" -18" DIAMETERS
---------6" MACHINE 2-1/2" - 6" WIDE BLANKS
---------OR
---------12" MACHINE 6" - 12" WIDE BLANKS
SPEED 100 FPM (APPROX.)
MOTOR 2 HP /230/3/60/ 1,800 RPM
DRIVE DOUBLE V BELT
BASE ARC WELDED STEEL
DIMENSIONS 56" L x 24" W
WEIGHT 750 LBS. (APPROX.)
THIS MACHINE WILL FORM THE SPIN COLLAR POCKET,
COIL, CRIMP AND BEAD. COMPLETE WITH HARDENED OUTRIGGER GUIDE.
OPTIONAL: NOTCHER
