FLAGLER SHEET GANG SLITTER / BEADER - LIGHT DUTY

NEW "FLAGLER" SHEET GANG SLITTER/BEADER- LIGHT DUTY
CAPACITY SLITTER, 3 CUTS ON 22-26 Ga. (MILD STEEL)
BEADER, 3 BEADS ON 22-26 Ga. (MILD STEEL)
SPEED 60 FPM (APPROX.)
MOTOR 1/2 HP /115/1/60/ 60 RPM
DRIVE ROLLER CHAIN
BASE ARC WELDED STEEL

36" WIDE- GS-336 50" x 31" x 34", FEED TABLE HEIGHT 34", WEIGHT 535 LBS
48" WIDE- GS-348 62" x 31" x 34". FEED TABLE HEIGHT 34", WEIGHT 640 LBS
60" WIDE- GS-360 74" x 31" x 34". FEED TABLE HEIGHT 34", WEIGHT 745 LBS

The Flagler Sheet Gang Slitters comes standard with 3 pair of slitter knives.
This unit is available in 3 models -36", 48" and 60" widths.
A fully adjustable feed gauge allows for the slitting of any increments down to and including a 4" wide starting blank.
These Flagler slitters will slit bronze, aluminum, brass, and other materials as well as conventional galvanized sheets.
All blade assemblies are fully adjustable over width of the machine.
